Configuration:
1. Adopt industrial heavy duty steel structure, plate steel joint welding with square pipe steel, under heat treatment, will not deform after long time using.
2. Configure with Japan THK linear rail for all axis, to ensure durable and high precision for long time processing.
3. ഉയർന്ന കൃത്യതയുള്ള ഗ്രൈൻഡിംഗ് ടൈപ്പ് ഗിയർ റാക്ക്, ജപ്പാൻ ഷിമ്പോ റിഡ്യൂസർ, ഉയർന്ന വേഗതയും കൃത്യതയും ഉറപ്പാക്കാൻ കഴിയും, ഉയർന്ന കൃത്യതയുള്ള റോളിംഗ് ബോൾ സ്ക്രൂ ഉപയോഗിച്ച് Z ആക്സിസ് പ്രക്ഷേപണം ചെയ്യുന്നു.
4. Adopt France Schneider AC servo system for all axis, larger power, close-cycle control, high precision positioning, stronger torque force, dynamic corresponding time is shorter, and the overload resistance ability is strong.
5. Adopt industrial optical fiber cutting system, easy to install, maintenance and cam module based on autocad kernel development, built-in process, ensure high-quality cutting effect.
6. Adopt professional WSX, Raytools laser cutting head, imported optical lens, focus spot smaller, cutting lines more precise, higher efficiency and better processing quality can be ensured.
7. Dual air path control, equipped with Japan SMC intelligent gas unit, automatic pressure regulation, air exchange, pressure detection, more simple to use.
8. Fiber laser transmitting, flexible processing, realized high accuracy cutting on every point.
9. Compatible with multiple software, can design ant graphic and letters as you like, operating simple, flexible and easy.
| മോഡൽ | FC1325 | FC1530 | FC1540 | FC1560 |
| working size(X&Y) (mm) | 1300*2500 മി.മീ | 1500*3000 മി.മീ | 1500*4000mm | 1500*6000mm |
| Laser medium | ഫൈബർ ലേസർ | |||
| ലേസർ ശക്തി | 800w, 1000w, 1500w, 2000w (Optiona) | |||
| കട്ടിംഗ് കനം | According to the material and power | |||
| 0.1minimum Route Width | 0.1 | |||
| repeat precision | ± 0.05 | |||
| Aiming Positioning | Red Dots | |||
| Wave Length | 1080 മി.മീ | |||
| വൈദ്യുതി വിതരണം | 220-380V、50HZ | |||
സവിശേഷതകൾ
1. Adopt heavy duty structure, CNC machinery center processing and forming, high strength and good stability;
2. More stronger cast iron stand to keep the machine working more stable;
3. Configure with high accuracy THK linear rail, high accuracy helical gear rack transmitting,more stability,higher precision;
4. Restart from power off, auto feeding, restoration, continue processing at break point. Support 9 coordinate setting, user friendly design;
5. Configured with SUDA 3 in 1 control system, quickcalculation, strong anti-interference ability;
6. Equipped with industrial camera,the probe is clear. High positioning precision;
7. Standard configured with 380V 5.5KW high speed water cooling spindle motor, high power high efficiency;
8. Independent control cabinet, stronger power and weak power separate, maintenance easily;
9. Be compatible with many CAD/CAM software like Type3/Artcam/Castmate/Probe/UG/Artgrave etc;
10. Standard with industrial matrix vacuum system;
11. Configure with manual oil lubrication system. Equipment maintenance is more convenient and quick.
Main Parts
Machine Structure
The machine structure adopts industrial heavy steel structure, under heat treatment, suffer lower temperature tempering and annealing, won't deform after long time use. the machine base is very stable when the processing.
Japan THK Linear Rail and Block
The machine adopts the best linear and block rail from Japan. We have the feedback from our client that its block even can use over 10 years and can't break.The usage lifespan and the product quality definitely can be ensured.
France Schneider Servo System
The fiber laser machine adopts the imported servo system from France including servo motor and servo driver, The Y axis two servo motor power are 2KW, The X axis servo power is 2KW power, The Z axis servo motor power is 0.4KW power.
CYPCUT Control System
The best control system in fiber laser machine industry,
It is suitably applied to high power fiber laser machine and can support the rotary device, exchange table and automatic focus cutting head.
S & A Chiller
Focus on the research and development of industrial cold machine, independent research and development of core parts strictly implement ISO production management system, With excellent quality and leading research retrength, S &A has become a leding enterprise in the domestic industrial refrigeration industry.
Raycus Laser Source
Fiber laser is compact in structure, stable in performance and widely used, Fiber laser has high photoelectric conversion efficiency, good beam quality and low maintenance cost,(The USA IPG Laser source is optional)
Japan Shimpo Servo Reducer
Our fiber laser machine adopts the Shimpo Servo Reducer from Japan with low noise when the machine is processing the metal materials,After many refinements,it has small size in installation but high precision function.
WSX Fiber Laser Cutting Head
Our fiber laser machine 1000 watt install the WSX NO:1 manual focus cutting head.
The machine also can optional the NC30 automatic focus cutting head, Fast perforation (especially the thick materials), The plate is not easy to heat, Does not affect the cutting head following.
Oil Lubrication System
This machine accessory is applied to lubricate the machine rail and block in order that it runs smoothly and fast, improving the working efficiency.
Application&Sample
വിശദാംശങ്ങൾ
- Application: LASER CUTTING, laser cutting
- Applicable Material: Metal, aluminum Cooper carbon stainless steel
- അവസ്ഥ: പുതിയത്
- ലേസർ തരം: ഫൈബർ ലേസർ
- Cutting Area: 1300*2500mm
- Cutting Speed: 20m/min
- Graphic Format Supported: AI, PLT, DXF, Dwg
- Cutting Thickness: depending on the materials
- CNC അല്ലെങ്കിൽ അല്ല: അതെ
- കൂളിംഗ് മോഡ്: വാട്ടർ കൂളിംഗ്
- Control Software: Schneider AC servo system
- ഉത്ഭവ സ്ഥലം: അൻഹുയി, ചൈന
- ലേസർ ഉറവിട ബ്രാൻഡ്: RAYCUS
- ലേസർ ഹെഡ് ബ്രാൻഡ്: WSX
- സെർവോ മോട്ടോർ ബ്രാൻഡ്: ഷ്നൈഡർ
- Guiderail ബ്രാൻഡ്: THK
- നിയന്ത്രണ സിസ്റ്റം ബ്രാൻഡ്: Cypcut
- Weight (KG): 2900 KG
- പ്രധാന വിൽപ്പന പോയിന്റുകൾ: ഉയർന്ന സുരക്ഷാ നില
- ഒപ്റ്റിക്കൽ ലെൻസ് ബ്രാൻഡ്: തരംഗദൈർഘ്യം
- വാറന്റി: 1 വർഷം
- Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Retail, Printing Shops, Construction works , Energy & Mining, Advertising Company
- മെഷിനറി ടെസ്റ്റ് റിപ്പോർട്ട്: നൽകിയിട്ടുണ്ട്
- വീഡിയോ ഔട്ട്ഗോയിംഗ് ഇൻസ്പെക്ഷൻ: നൽകിയിട്ടുണ്ട്
- പ്രധാന ഘടകങ്ങളുടെ വാറന്റി: 1 വർഷം
- Core Components: Motor, Gear, Engine, PLC, laser power
- പ്രവർത്തന രീതി: തുടർച്ചയായ തരംഗം
- കോൺഫിഗറേഷൻ: 3-അക്ഷം
- കൈകാര്യം ചെയ്യുന്ന ഉൽപ്പന്നങ്ങൾ: ഷീറ്റ് മെറ്റലും ട്യൂബും
- ഫീച്ചർ: വാട്ടർ-കൂൾഡ്
- Product name: FC1325 FC1530
- Laser power: 1000W
- Laser source: Raycus (optional IPG)
- Servo motor: France Schneider
- Laser head: WSX /Raytools
- Positioning Accuracy: 0.05 Mm
- Linear rail: Japan THK
- Reducer: Japan Shimpo reducer
- പ്രവർത്തന മേഖല: 3000*1500 മിമി
